Submersible pumps for clear water - C80
Jacket cooled submersible drainage pumps, low suction, for permanent operation
Specifications:
Spherical clearance
1 mm
Discharge size
G 3/4
Max. head
3,0 m
Max. flow
2,8 m³/h
Motor power P1
0,08 kW
Motor power P2
0,04 kW
Characteristics
Submersible pumps for clear water - C80
Application
The C 80 scavenger is suitable for irrigation, water transfer and drainage in clear water. For flat-water exhaust to min. 2 mm. Pumping water from collection tanks, for flood relief and water removal from water courses or reservoirs. Suitable also for water circulation in garden ponds and cascades.
Installation
Permanent or transportable.
Materials
Motor housing, motor shaft, screws (Stainless steel), Suction sieve, pump housing (Wear resistant synthetic material, composite), Impeller (Glass-fibre, reinforced synthetic material (composite)), Elastomere (NBR).
Pumped liquid
Clear water containing soft solids with a diameter of max. 1 mm. Max. liquid temparature: 35°C short term up to 60°C.
Motor
Canned wet-rotor, seal-less, rotor shaft lubricated by pumped liquid. Insulation class B. Motor protection IP 68.
Features
The water jacket cooled motor with the top discharge protects the motor against overheating even during sip operation.
Impeller
Impeller of the C80 series.
For optimum adaptation to the pump medium and operating conditions.
Open multi-channel impeller
For dirty and muddy media with solids.
The network frequency is 50 Hz in the EU.
In other parts of the world, such as in the North American region, Brazil, Saudi Arabia or South Korea 60 Hz.
HOMA pumps are available for both frequency ranges. A selection of the pumps for the valid frequency range at the installation site must be made accordingly. We are happy to assist you in the selection of the right pumps.
At this point, you exit the HOMA website and are directed to the website offering our pump selection software HOP.Sel.
Frequency
50 Hz
